CASTER LEVELLER DS 1325 SERIES(경하중용)
페이지 정보
작성자 최고관리자 조회15회 작성일 26-06-14 16:02-
-
-
DS 1325 SERIES(경하중용)
-
-
Structure
Color Theme
Menu Drop
![](http://www.kgindus.co.kr/data/file/gallery/b85c387376cf6e7fd552fe6e1d23795e_xUgbnA3z_3eab4a30609eae85740d9147edd3f745a750d367.jpg")
![](http://www.kgindus.co.kr/data/file/gallery/b85c387376cf6e7fd552fe6e1d23795e_XxZF8iR4_2de82eda5a18153fc72b3dd47b4fbfeb0912871f.jpg")
![](http://www.kgindus.co.kr/data/file/gallery/b85c387376cf6e7fd552fe6e1d23795e_IrpmLM8S_ea3558b180d7f58decacf20fd0e5282af12cea5a.jpg")
![](http://www.kgindus.co.kr/data/file/gallery/b85c387376cf6e7fd552fe6e1d23795e_x8HZJoiq_2e9f2e9b2e7964f803dfb6f641b25b36ba0cddba.jpg")
제품명 (Model) | Wheel Dia (mm) | Tread Width (mm) | Wheel Material | Bearing | Load Height (mm) | Load Height (mm) | Swivel Radius (mm) | Load Capacity (kg) | 박스당수량 PCS |
|---|---|---|---|---|---|---|---|---|---|
| DS 1325 PUB | 61 | 25 | Poly Urethane | 628ZZ | 85 | 91 | 58 | 70 | 80 |
| DS 1325 MRB | 61 | 25 | Mirage Rubber | 628ZZ | 85 | 91 | 58 | 60 | 80 |
| DS 1325 EPU | 64 | 24 | Elastic Poly Urethane | 608ZZ | 87 | 93 | 60 | 60 | 80 |
